Tilt Range
-30 – 110°
Workpiece Wt
150 kg (0°) / 100 kg (0–90°)
| Machine Information | |
|---|---|
| Machine State | Used |
| Condition | Very Good |
| Machine Source | Fresh Imported from Canada |
| Quantity Available | 1 |
| Rotary Table (4th / 5th Axis) | |
|---|---|
| Number of Axes | 5th Axis |
| Tilt Range | -30 – 110 ° |
| Table Diameter | 320 mm |
| Table Height at 0° Position | 355 mm |
| Centre Height at 90° Position | 255 mm |
| Centre Bore | 102 mm |
| Servo Motor (Company & Model) — Rotary | |
16
Years
Family-Run Legacy
2,500+
Machines
Successfully Traded
Pan-India
Network
Buyers & Sellers
Mohali
Punjab
Headquarters
Typically responds within a few hours
| Fanuc a-8i |
| Servo Motor (Company & Model) — Tilt | Fanuc a-8i |
| Max Motor Speed | 4000 rpm |
| Speed Reduction Ratio | 1/240 |
| Max Table Speed | 16.7 rpm |
| Clamp System | Hydraulic |
| Clamping Torque (Nm @ psi) | 2200 Nm @ 500 psi |
| Accuracy — Tilting | ±22.5 |
| Weight | 440 kg |
| Allowable Workpiece Weight at 0° Tilt | 150 kg |
| Allowable Workpiece Weight at 0–90° Tilt | 100 kg |
