| Machine Information | |
|---|---|
| Machine State | Used |
| Condition | Excellent |
| Machine Source | Fresh Imported from Malaysia |
| Quantity Available | 3 |
| Axis Specifications | |
|---|---|
| Travel X | 350 mm |
| Travel Y | 250 mm |
| Travel Z | 350 mm |
| Rapid X | 50 m/min |
| Rapid Y | 50 m/min |
| Rapid Z | 50 m/min |
| Number of Axes | 3 |
| Spindle Specifications | |
|---|---|
| Spindle Power | 6.4 kW |
| Spindle Nose to Table | 200 – 550 mm |
| Spindle Speed | 22000 rpm |
| Spindle Taper | BT30 |
| Spindle Type | Integral |
| Table & Workholding | |
|---|---|
| Table Size | 500 × 270 mm |
| ATC Tool Capacity | 26 |
| No. of Pallets | Double |
| Pallet Type | Rotating |
| Max Table Load | 80 kg |
| Control & Electrical | |
|---|---|
| Controller Company | Brother |
| Controller Model | B Series |
| Other Specifications | |
|---|---|
| Guideways Type | LM |
| Weight | 2500 kg |
| Running Condition | Working |
